| ORDER NO, | 7 9011 0010 |
| Energy source | Pneumatic |
| Piston dia. | 26.00 mm |
| Piston stroke | 125.50 mm |
| Piston weight | 765 g |
| Shank | MT2 |
| Impacts | 1,080 rpm |
| Air consumption | 0.64 m³/min |
| Length | 565.00 mm |
| Connection | R3/8"female |
| Noise level LpA | 100.0 dB(A) |
| Noise level LWA | 111.0 dB(A) |
| Vibration level | 20.4 m/s² |
| Weight | 5.1 kg |
| Fields of application / branch | Metal industry and steel construction; Plant and mechanical construction |
| ORDER NO. | Description |
|---|---|
| 9 2406 0260 | Portable service unit with pressure regulator 3/4“ |
| 9 2406 0630 | Portable service unit with protection housing and pressure regulator 1/2“ |
| 9 2406 0650 | Portable service unit with protection housing and pressure regulator 3/4“ |
| ORDER NO. | Description |
|---|---|
| 9 3610 0410 | Pneumatic pressure hose ID 13 mm, 2.5 m length, with screw-on claw coupling |
| 9 3610 0420 | Pneumatic pressure hose ID 16 mm, 2.5 m length, with screw-on claw coupling |
| 9 3610 0430 | Pneumatic pressure hose ID 19 mm, 2.5 m length, with screw-on claw coupling |
| 9 2102 0020 | Claw coupling, metal sealing, 3/4” ID |
| Sand rammer feet on request. |
