| ORDER NO. | 2 3060 0010 |
| Energy source | Hydraulic |
| Operating pressure | 90-140 bar |
| Tool holder | MT3 |
| Direction of rotation | right/left |
| Max. drill bit dia. | 32.00 mm |
| Max. drilling depth | 12,000.00 mm |
| Torque | 60 Nm |
| Speed (fre) | 280 rpm |
| Power | 1.60 kW |
| Volume flow | 10-45 l/min |
| Connection | M18x1.5 mm |
| Hydraulic hose connection | Flat-Star A250-OM/OF-1/2”BSP |
| Hydraulic medium | Hydraulic oil |
| Hydraulic circuit type | open circuit |
| Oil filtration class | ISO-level of purity 20/18/13 |
| Temperature of oil | -34 up to +82 °C |
| Viscosity of oil | >13 centistokes |
| Noise level LpA | 85.0 dB(A) |
| Noise level LWA | 96.0 dB(A) |
| Vibration level free (in lime sandstone) | <2.5 m/s² |
| Weight | 8.5 kg |
| Fields of application / branch | Plant and mechanical construction; Underwater Work |
| ORDER NO. | Description |
|---|---|
| 9 9902 0120 | Multi oil for cleaning and protection |
