| ORDER NO. | 8 1603 0300 |
| Energy source | Pneumatic |
| Operating pressure | 5 bar |
| Nominal diameter | 300 mm |
| Volume flow (unrestricted) | 0.78 m³/s |
| Air consumption | 0.58 m³/min |
| Length | 350.00 mm |
| Quality of air | oil free |
| Noise level LpA | 85.0 dB(A) |
| Weight | 14.0 kg |
| Fields of application / branch | Energy and pipeline construction; Metal industry and steel construction; Plant and mechanical construction |
| ORDER NO. | Description |
|---|---|
| 8 1601 2070 | Protective grill |
| ORDER NO. | Description |
|---|---|
| 9 3001 0010 | Flange according to DIN 21 603 |
| ORDER NO. | Description |
|---|---|
| 9 3709 0260 | Connecting piece, antistatic |
| ORDER NO. | Description |
|---|---|
| 9 3709 0300 | Quick collar, antistatic |
| ORDER NO. | Description |
|---|---|
| 9 3709 0220 | Air duct, antistatic, 5m |
| ORDER NO. | Description | Nominal dia. [mm] | Reducing to dia. [mm] |
|---|---|---|---|
| 9 3703 0280 | Adapter | 300 | 80 |
| 9 3703 0290 | Adapter | 300 | 100 |
| 9 3703 0300 | Adapter | 300 | 150 |
| 9 3703 0050 | Adapter | 300 | 200 |
| ORDER NO. | Description |
|---|---|
| 9 3703 0050 | Earthing cable |
