Angle Grinder

Order Number: 1 5035 0020
The most powerful pneumatic angle grinders for 125 mm grinding wheel diameter.
Energy source: Pneumatic
Energy source: Pneumatic
Operating pressure: 6 bar
Operating pressure: 6 bar
Actuation: Twist throttle
Actuation: Twist throttle
Speed (free): 12,000 rpm
Speed (free): 12,000 rpm
Disc dia. max.: 125 mm
Disc dia. max.: 125 mm

Technical Data

ORDER NO. 1 5035 0020
Energy source Pneumatic
Operating pressure 6 bar
Valve type Twist throttle
Max. disc dia. 125.00 mm
Tool holder/thread 22.2/M14 mm
Air consumption 0.85 m³/min
Power 0.70 kW
Speed (free) 12,000 rpm
Connection R1/4"male
Noise level LpA 85.6 dB(A)
Vibration level <2.5 m/s²
Weight 2.0 kg
Fields of application / branch Metal industry and steel construction; Plant and mechanical construction

Accessories

ORDER NO. Description Connection (thread/size)
9 3610 0180 Hose, length 2.5 m with automatic oiler R 1/4" R 1/4’’ male
9 3610 0350 Hose, length 2.5 m with automatic oiler R 1/2" R 1/2’’ male
9 3610 0200 Hose, length 2.5 m only R 1/4’’ male
9 2406 0050 Service unit with filter and oiler R 1/2’’ male
9 2406 0140 Service unit with filter, oiler and pressure regulator R 1/2’’ female
9 2406 0080 Service unit with filter and oiler R 3/4’’ innen
9 2406 0170 Service unit with filter, oiler and pressure regulator R 3/4’’ female
9 2406 0630 Service unit with protection housing, filter and pressure regulator R 1/2“male
9 2406 0650 Service unit with protection housing, filter and pressure regulator R 3/4“ male
9 1301 0100 Open-ended spanner DIN 894 SW 24
9 1417 0080 Pin spanner 11-60 (dia. 4) mm
9 2818 0010 Rubber disc for angle grinder Type 1 50…, 1 1470…-1 1474… 125.00 mm
9 2818 0020 Rubber disc for angle grinder Type 1 50…, 1 1470…-1 1474… 178.00 mm
9 9910 0090 Carrying case for Type 1 1470…, 1 1472..., 1 1474..., 1 4312..., 1 50...
Scrub discs, cutting wheels, flap discs, fibre discs and twist- knot/ cup brushes on request.
