| ORDER NO. | 5 6042 0010 |
| ATEX Specification | II2GExhIIBT6Gb |
| Energy source | Hydraulic |
| Operating pressure | 90-140 bar |
| Volume flow | 15-50 l/min |
| Power | 1.5 kW |
| Free surface speed | 76 m/min |
| Cutting capacity max. dia. | 120,00 mm |
| Cutting capacity max. □ | 120x180 (4“x7“) mm |
| Total length | 630.00 mm |
| Height incl. motor | 270.00 mm |
| Width | 200.00 mm |
| Connection | M18x1.5 mm |
| Hydraulic hose connection | Flat-Star A250-OM/OF-1/2”BSP |
| Hydraulic medium | Hydraulic oil |
| Fluid circulation | open circuit |
| Oil filtration class | ISO-level of purity 20/18/13 |
| Temperature of oil | -34 up to +82 °C |
| Viscosity of oil | >13 centistokes |
| Noise level LpA | 81.4 dB(A) |
| Noise level LwA | 92.4 dB(A) |
| Vibration level | 2.8 m/s² |
| Weight | 10.4 kg |
| Fields of application / branch | Energy and pipeline construction; Metal industry and steel construction; Plant and mechanical construction |
| ORDER NO. | Teeth per inch |
|---|---|
| 9 2506 0410 | 6/10 |
| 9 2506 0110 | 8/12 |
| 9 2506 0100 | 10/14 |
| 9 2506 0120 | 14 |
| ORDER NO. | For cutting |
|---|---|
| 5 6032 9400 | Pipes |
| 5 6032 9500 | Underground roof supports |
| ORDER NO. | Description |
|---|---|
| 2 1317 9010 | Hydraulic hose set |
| 9 9902 0120 | Multi oil for cleaning and protection |
